Our produced Twisted Pair Drop Wire cover the requirements for BroadBand use, between the D.P. box (last cable distribution point) and the subscriber’soffice.

Each conductor shall consist of a well annealed electrolytic copper wire of 0.6 mmdia, of uniform quality, smoothly drawn and of circular cross section. The wire shallbe free from oxide flakes and other defects. The diameter at any cross section shallnot deviate from the specified nominal value by more than: ( + 0.02 mm ), ( – 0.01mm )

The tensile strength of the conductor is at least 200 MPa. The conductorshall not break when a sample length is closely wrapped 3 turns round a wire of itsown diameter; thencarefully unwrapped and again closely wrapped three times insuch a way that the wire is bent in the opposite direction.

The resistance of the conductor is based on a copper of resistivity notgreater than 17.241 ohms mm2/km at 20
